Page34 CREASING/FOLDING
SECTIONK
MainFoldRollers-Removal
RemoveThe2ndFoldRollerAssemblyasfollows:-
RemoveThe1stFoldRollerAssemblyasfollows:-
1.Removethewormwheelfromtheshaft.
2.Remove3offscrewsonaccesshousingand1offonlinkplate.
3.Therollerassemblycannowbewithdrawnfromthelaysideofthemachine.
1.Remove3offscrewsonaccesshousing.
2.Therollerassemblycannowbewithdrawnfromtheoperatorsideofthemachine.
