Morgana Digifold Pro CB - Page 43

Page43
2.2.
2.3.
2.4.
2.5.
RemovetheBallsfromtheSidelay
OpentheInputRollergapfullybyreleasingtheLockingScrewandusingthe4mm
hexagonkeytomoveitdowntowardstheLoadingTable.(SeeFIG.2.3below).
PlaceaTestSheetontheLoadingTablewithitsLayEdgeagainsttheFixedSideLay&
slideitthroughtheopenInputRollersuntiltheleadedgejustenterstheDynaCrease
Unit.
Itshouldbepossibletovisuallychecktheparallelalignmentoftheleadedgeofthe
sheetwiththeUpperTieBaroftheDynaCreaseUnit.(SeeFIG.2.5).
Donotusedamagedtestsheets.
WARNING.
FIG.2.3
SideLay(Manifold)
InputRollers
Paper
Dynacrease
Fixed
TieBar
FIG.2.5
LeadingEdgeof
TestSheet
OperatorSide
LockingScrew
DigifoldPro
SYSTEM
