CleaningSensors
LeadEdgeSensor
FoldRollers(ClipSensors)
Theleadedgesensorhousingislocatedonthelayedgesideofthemachine
betweentheinputrollershafts.
canbeblownwithcompressedair.
can
becleanedwhenrequiredusingaslimbrush.
Clip2sensorissituatedontheupperguidesinsidethetopcoverandcanbe
cleanedwhenrequiredusingaslimbrush.
Withaslimbrushthesensorscanbecleanedwhenrequired.Passthebrushunder
theballholderandpushthroughuntilitpassestheinfeedrollers,ascanbeseeninthe
picturebelow.
Alternativelyit
TheJamSensorissituatedjustaftertheedgesensorandisinlineacrossthepaper
pathwiththereceiverintheoperatorsidesideplate.Thisisnotusualysensitivetodustbut
ifrequiredcanbeblownwithcompressedair.
Clip1sensorissituatedonthelowerguidesbeneaththedeliveryconveyorand
