9.4.RotatetheDelrincam
9.5.
9.6.
downwardsuntilthejigassemblyfitscorrectly,adjustthe
eccentricshaftifrequired,tightenthetwocapheadscrewsontheends
oftheeccentricshaft.
RemovetheRightHandShoulderBoltfromtheSettingJig,rotatetheJig(andtheKnife
DriveHubtowhichitisfixed)andthedrivemotorpulley,fullyClockwiseandinsertthe
ShoulderBoltthroughthepreviouslyunusedholeintheJig
andintotheLeftHandKnifeDriveHub.Thislockstheknivesintheotherofthetwo
correctstoppositions.
Re-CheckthepositionsoftheSettingJig.Repeataboveprocedureiftheshoulder
screwsdonotslideintothejigsmoothly
(whichshouldnowbeonthe
right)
