Page47
3.6.AdjustthetensionofthebylooseningthefourCapHeadfixings
securingtheVacuumDriveMotortotheVacuumStepperPlate.RotatetheMotor
aboutitstoplefthandfixinguntilthecorrecttensionisachieved&tightenallfixings
VacuumDriveBelt
FIG.3.4A FIG.3.4B
FIG.3.4C
Vacuum
Roller
Vacuum
DriveBelt
Vacuum
MotorFixings
Vacuum
StepperPlate
AdjustTension
DigifoldPro
SYSTEM
