Chapter 4 Installation Gen 3 Site Controller System Manual
Intercabling Connections
4-48 68P80801E30-A 5/1/2002
210 System/Alarm Control 23, 48 reserved for system use
211 User Alarm/Control 7, 32 customer defined input
212 User Alarm/Control 22, 47 customer defined input
213 User Alarm/Control 21, 46 customer defined input
214 User Alarm/Control 20, 45 customer defined input
215 User Alarm/Control 19, 44 customer defined input
216 User Alarm/Control 18, 43 customer defined input
217 User Alarm/Control 17, 42 customer defined input
218 User Alarm/Control 16, 41 customer defined input
219 System/Alarm Control 7, 32 predefined input, site entry
220 System/Alarm Control 8, 33 predefined input, site high
ambient temperature
221 System/Alarm Control 9, 34 predefined input, site low
ambient temperature
222 System/Alarm Control 10, 35 predefined input, site smoke
detector
223 System/Alarm Control 11, 36 predefined input, site AC
surge protector
224 System/Alarm Control 22, 47 reserved for system use
225 RF #3 1, 2 RF Cabinet 3 circuit breaker
226 RF #3 3, 6 RF Cabinet 3 combination/mc
amplifier
227 RF #3 5, 8 RF Cabinet 3 combination/mc
power supply
228 RF #3 7, 4 RF Cabinet 3 Tower Top
Amplifier
229 RF #2 1, 2 RF Cabinet 2 circuit breaker
230 RF #2 3, 6 RF Cabinet 2 combination/mc
amplifier
Table 4-23 Punch block pinouts — continued
Alarm
code
EAS/EAS2
connector
Punch
block
pairs
EAS/EAS2 standard
alarm connection
To Next Page
