68P80801E30-A 5/1/2002 4-49
Gen 3 Site Controller System Manual Chapter 4 Installation
Intercabling Connections
231 RF #2 5, 8 RF Cabinet 2 combination/mc
power supply
232 RF #2 7, 4 RF Cabinet 2 Tower Top
Amplifier
233 RF #1 1, 2 RF Cabinet 1 circuit breaker
234 RF #1 3, 6 RF Cabinet 1 combination/mc
amplifier
235 RF #1 5, 8 RF Cabinet 1 combination/mc
power supply
236 RF #1 7, 4 RF Cabinet 1 Tower Top
Amplifier
237 CONTROL 1, 2 Control Cabinet circuit
breaker
238* CONTROL 3, 4 output, RF Relay Cabinet 1
239* CONTROL 5, 6 output, RF Relay Cabinet 2
240* CONTROL 7, 8 output, RF Relay Cabinet 3
241 System/Alarm Control 21, 46 reserved for system use
242 System/Alarm Control 12, 37 AC Power failure
243 System/Alarm Control 13, 38 low DC voltage
244 System/Alarm Control 14, 39 high DC voltage
245 System/Alarm Control 15, 40 breaker failure alarm
246 System/Alarm Control 16, 41 minor rectifier module failure
247 System/Alarm Control 17, 42 major rectifier failure
248* System/Alarm Control 30, 6, 5 customer defined output.
generator remote start
249 System/Alarm Control 20, 45 reserved for system use
250 System/Alarm Control 19, 44 reserved for system use
251 System/Alarm Control 18, 43 reserved for system use
252 User/Alarm Control 15, 40 customer defined input
Table 4-23 Punch block pinouts — continued
Alarm
code
EAS/EAS2
connector
Punch
block
pairs
EAS/EAS2 standard
alarm connection
