Motorola iDEN Site Controller User Manual

68P80801E30-A 5/1/2002 4-9
Gen 3 Site Controller System Manual Chapter 4 Installation
Intercabling Connections
6-10 Channel Cavity Omni Site Cables
Table 4-2 lists the required cables for a 6-10 channel cavity omni site.
Table 4-26-10 Channel Cavity Omni Site Intercabling
Cable PN Description Qty. Connection
0112004Z29 Ethernet 1 Site controller to Main RF Cabinet
0112004Z29 Ethernet 1 Main RF Cabinet to Expansion RF
Cabinet
0112004Z29 5 MHz/1 PPS 1
Site controller to Main RF Cabinet
0112004Z29 5 MHz/1 PPS 1 Main RF Cabinet to Expansion RF
Cabinet
3084225N42 Alarms 1 Control Cabinet to Main RF Cabinet
3084225N42 Alarms 1 Control Cabinet to Expansion RF
Cabinet
0182004W04 Phasing Harness 1 Main RF Cabinet/Expansion RF
Cabinet
0112004B24 Receive
Expansion
Cabling
3 Main RF Cabinet to Expansion RF
Cabinet
