Motorola MBX Series User Manual

Adding DRAM
http://www.motorola.com/computer/literature 1-13
1
Caution
Caution
Avoid touching areas of integrated circuitry; static discharge can damage
circuits.
Use ESD
Wrist Strap
ESD
Attach an ESD strap to your wrist. Attach the other end of the ESD strap
to an electrical ground. (Note that the system chassis may not be grounded
if it is unplugged.) The ESD strap must be secured to your wrist and to
ground throughout the procedure.
1. While the MBX can accept changes in DRAM configuration with
power applied to the system, we recommend that you perform a system
shutdown and disconnect the AC or DC power source before adding
DRAM. Inserting or removing modules with power applied may result
in damage to module components.
2. Insert the desired DRAM DIMM into XU3 and secure the DIMM with
the clips at each end of the socket.
3. Configure jumper headers J8, J9, and J10 to match the size of the
DRAM module as shown in the following illustration. These jumpers
