Installation Procedures
1
specify the address width appropriate for the amount of expansion
memory installed.
Replacing Lithium Batteries
Follow these safety rules for proper battery operation and to reduce
equipment and personal injury hazards when handling lithium batteries.
Use the battery for its intended application only.
Note Do not recharge, open, puncture or crush, incinerate, expose to
high temperatures or dispose of in your general trash collection.
To replace the lithium battery, observe the following guidelines and follow
the steps below.
Note When replacing the battery, power must be applied to the board
to prevent data loss.
Warning
War ni ng
To prevent serious injury or death from dangerous voltages, use extreme
caution when handling, testing, and adjusting this equipment and its
components.
2152 9805 (i)
J8
8MB
(factory
configuration)
J9 J10
1 2 3 1 2 3 1 2 3
1 2 3 1 2 3 1 2 3
1 2 3 1 2 3 1 2 3
1 2 3 1 2 3 1 2 3
16MB
32MB
64MB/
128MB
