4 - 18 MC31XX Series Mobile Computer User Guide
Shoulder Strap
Remove the detachable belt clip (see Figure 4-10 on page 4-17) and attach the shoulder strap.
Figure 4-12 Attach the Fabric Holster To the Shoulder Strap
The Fabric Holster holds the mobile computer on a belt or waist band.
1. To insert the mobile computer, slide the mobile computer into the Fabric Holster with the screen facing the
user.
2. Pull restraining strap over mobile computer and secure in the clip.
3. To remove the mobile computer, pull down on restraining strap to release from clip and lift retaining strap clear.
4. Lift mobile computer out of Fabric Holster.
Figure 4-13 Insert and Remove the Mobile Computer
Clip Release
Shoulder Strap
