A - 4 MC3000 User Guide
EMI/RFI Batch Version
USA:
FCC Part 15
Canada
: ICES 003 Class B
EU:
EN55022 Class B EN55024
Japan:
CISPR 22, Class B
Australia:
AS3548
Laser Safety IEC Class2/FDA Class II in accordance with IEC60825-1/EN60825-1
Data Capture Specifications
Options 1D laser scanner
2D imager
Laser 1D Scanner (SE950) Specifications
Range on 100% UPCA Near: 3.8 cm (1.5 in.) Far: 60 cm (24 in.)
Optical Resolution 0.004 in. minimum element width
Roll +/- 35° from vertical
Pitch Angle +/- 65° from normal
Skew Tolerance +/- 50° from normal
Ambient Light 10,000 ft. candles/107,640 lux
Scan Rate 104 (+/- 12) scans/sec (bidirectional)
Scan Angle 47° ± 3° default; configurable narrow angle: 35° ± 3°
2D Imager Engine (SE4500-SR) Specifications
Range on 100% UPCA at
30 ft./candles
Near: 6.35 cm (2.5 in.) Far: 36.07 cm (14.2 in.)
Field of View Horizontal - 38°
Vertical - 25°
Optical Resolution 752 x 480 pixels
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light 9,000 ft. candles (96,900 Lux)
Focal Distance from Front of
Engine
Near: 4 cm (1.6 in.)
Far: 38 cm (15 in.)
Aiming Element (VLD) 655 nm +/- 10 nm
Illumination Element (LED) 625 nm +/- 5 nm
Table A-1
MC31XX Technical Specifications (Continued)
Item Description
