Getting Started 1 - 7
Figure 1-7 Insert Battery
3. With the latches in the open position, replace the battery door, top first and press to close.
Figure 1-8 Insert Battery Door
4. Rotate the latches (to the lock position) to lock the door in place.
Figure 1-9 Close Latches
Battery
Door
Latches
