1 - 12 MC31XX Series Mobile Computer User Guide
6. With finger, press the battery clip in (at the top of the battery) and lift the battery out top first.
Figure 1-14 Remove Battery
To remove the main battery from an MC3190G:
1. If the MC3190G is in suspend mode, press the Power button to wake the device.
2. Press the Power button to place the MC3190G in suspend mode.
3. Wait for the red Scan LED to turn on and then turn off.
4. Rotate the latches to the open position.
Figure 1-15 Open Latches
5. Lift the door off, bottom first.
WARNING! Do not use a tool to remove the battery.
Battery Clip
NOTE On devices with Windows Mobile 6.5.3, a dialog box appears when pressing the Power button. See Removing
the Battery on page C-13 for more information.
CAUTION Do not lift up on the latches when removing the door. Lift up on the handstrap only.
