3 - 22 MC31XX Series Mobile Computer User Guide
Figure 3-27
Connection Favorite Options Window
8. In the Favorite Name text box, enter a name for this service that will appear in the Favorite window.
9. Tap Next. The Connection Summary window appears.
10. Tap Connect. The Select Dial-up Networking Entry window appears.
Figure 3-28
Select Dial-up Networking Entry Window
11. Select the entry and tap OK. The MC31XX begins to communicate with the Bluetooth phone. If required, the
phone requests permission to communicate with the MC31XX.
12. Confirm the connection on the phone. The Network Log On window appears.
Figure 3-29
Network Log On Window
13. In the User name text box, enter the user name for this connection.
14. In the Password text box, enter the password for this connection.
15. In the Domain text box, enter the domain name for this connection, if required.
16. Tap Finish or Connect.
17. The phone begins dialing and connects to the network.
