Power Amplifier Parts List (UHF) – CLE6216 3-59
R4333 0613952H95 CER CHIP RES 8200Ω 5%
0603
R4334 0613952J05 CER CHIP RES 15KΩ 5%
0603
R4336 0613952H73 CER CHIP RES 1000Ω 5%
0603
R4342 0613958H49 CER CHIP RES 100Ω 5%
0805
R4343 0613958H49 CER CHIP RES 100Ω 5%
0805
R4344 0613952J49 CER CHIP RES 1.0MΩ 5%
0603
R4350 0613958A89 CER CHIP RES 8.25Ω 1%
0805
R4352 0613958A89 CER CHIP RES 8.25Ω 1%
0805
R4412 0613959B34 CER CHIP RES 22.1Ω 1%
1210
R4415 0685357Y01 RES FIXED CHIP .0100 1
1W EPP
R4433 0613952H95 CER CHIP RES 8200Ω 5%
0603
R4434 0613952J05 CER CHIP RES 15KΩ 5%
0603
R4436 0613952H73 CER CHIP RES 1000Ω 5%
0603
R4442 0613958H49 CER CHIP RES 100Ω 5%
0805
R4443 0613958H49 CER CHIP RES 100Ω 5%
0805
R4444 0613952J49 CER CHIP RES 1.0MΩ 5%
0603
R4450 0613958A89 CER CHIP RES 8.25Ω 1%
0805
R4452 0613958A89 CER CHIP RES 8.25Ω 1%
0805
R4512 0613959B34 CER CHIP RES 22.1Ω 1%
1210
R4515 0685357Y01 RES FIXED CHIP .0100 1
1W EPP
Circuit
Ref
Motorola Part
No
Description
R4533 0613952H95 CER CHIP RES 8200Ω 5%
0603
R4534 0613952J05 CER CHIP RES 15KΩ 5%
0603
R4536 0613952H73 CER CHIP RES 1000Ω 5%
0603
R4542 0613958H49 CER CHIP RES 100Ω 5%
0805
R4543 0613958H49 CER CHIP RES 100Ω 5%
0805
R4544 0613952J49 CER CHIP RES 1.0MΩ 5%
0603
R4550 0613958A89 CER CHIP RES 8.25Ω 1%
0805
R4552 0613958A89 CER CHIP RES 8.25Ω 1%
0805
R4612 0613959B34 CER CHIP RES 22.1Ω 1%
1210
R4615 0685357Y01 RES FIXED CHIP .0100 1
1W EPP
R4633 0613952H95 CER CHIP RES 8200Ω 5%
0603
R4634 0613952J05 CER CHIP RES 15KΩ 5%
0603
R4636 0613952H73 CER CHIP RES 1000Ω 5%
0603
R4642 0613958H49 CER CHIP RES 100Ω 5%
0805
R4643 0613958H49 CER CHIP RES 100Ω 5%
0805
R4644 0613952J49 CER CHIP RES 1.0MΩ 5%
0603
R4650 0613958A89 CER CHIP RES 8.25Ω 1%
0805
R4652 0613958A89 CER CHIP RES 8.25Ω 1%
0805
R4911 0685609Y06 RES CHIP 3-TERM ALN
10W 100Ω 2%
R4912 0685609Y06 RES CHIP 3-TERM ALN
10W 100Ω 2%
Circuit
Ref
Motorola Part
No
Description
R4921 0685609Y06 RES CHIP 3-TERM ALN
10W 100Ω 2%
R4922 0685609Y06 RES CHIP 3-TERM ALN
10W 100Ω 2%
R4931 0685609Y06 RES CHIP 3-TERM ALN
10W 100Ω 2%
R4932 0685609Y06 RES CHIP 3-TERM ALN
10W 100Ω 2%
RT4247 0685191Y02 THERMISTOR CHIP 1 KΩ
W18
RT4278 0685191Y02 THERMISTOR CHIP 1 KΩ
W18
U2500 5114014M27 IC,LNR V
REGLTR,ADJUSTABLE,1.
2V TO
37V,1.5A,SM,D2PAK,PB-
FREE
U4110 5871224H02 COUPLER 435-524MHZ 3
DB HYBRID
U4120 5871224H02 COUPLER 435-524MHZ 3
DB HYBRID
U4130 5871224H02 COUPLER 435-524MHZ 3
DB HYBRID
U4337 5185560Y01 IC, DIG POT,10K,SOIC
U4437 5185560Y01 IC, DIG POT,10K,SOIC
U4537 5185560Y01 IC, DIG POT,10K,SOIC
U4637 5185560Y01 IC, DIG POT,10K,SOIC
U4910 5871224H02 COUPLER 435-524MHZ 3
DB HYBRID
U4920 5871224H02 COUPLER 435-524MHZ 3
DB HYBRID
U4930 5871224H02 COUPLER 435-524MHZ 3
DB HYBRID
VR2200 4813977M04 DIODE,ZEN,MMBZ5225,S
M,SOT-
23,3V,10MA,.225W,ZEN,P
B-FREE
VR2201 4813977M18 DIODE,ZEN,MBZ5239,SM,
SOT-
23,9.1V,10MA,.225W,ZEN,
PB-FREE
Circuit
Ref
Motorola Part
No
Description
VR4222 4813977M16 DIODE,ZEN,MBZ5237,SM,
SOT-
23,8.2V,10MA,.225W,ZEN,
PB-FREE
VR4252 4813977M16 DIODE,ZEN,MBZ5237,SM,
SOT-
23,8.2V,10MA,.225W,ZEN,
PB-FREE
Circuit
Ref
Motorola Part
No
Description
