Receiver Parts List (UHF) – CRE4007 6-49
6.4 Receiver Parts List (UHF) –
CRE4007
Circuit
Ref
Motorola Part
No
Description
C1000 2115153H20 CAP,FXD,5.1PF,.1PF+/-
,+2%,-2%,50V-
DC,0402,C0G,CAP,
CERAMIC, CO
C1001 2115153H07 CAP,FXD,1.5PF,.1PF+/-
,+6.67%,-6.67%,50V-
DC,0402,C0G
C1002 2115153H12 CAP,CERAMIC
CHIP,2.4PF,.1PF+/-,+.1%,-
.1%,50V-
DC,0402,C0G,CAP,
C1003 2115153H10 CAP,CER CHIP,2PF,.1PF+/
-,+.1%,-.1%,50V-
DC,0402,C0G
C1004 2115153H19 CAP,FXD,4.7PF,.1PF+/-
,+.1%,-.1%,50V-
DC,0402,C0G
C1005 2115153H12 CAP,CERAMIC
CHIP,2.4PF,.1PF+/-,+.1%,-
.1%,50V-
DC,0402,C0G,CAP,
C1006 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1008 2115153H45 CAP,CERAMIC
CHIP,33PF,+1%,-1%,50V-
DC,0402,C0G
C1103 2113951C39 CAP,FXD,20PF,+1%,-
1%,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C1104 2113951C34 CAP,FXD,10PF,+1%,-
1%,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C1106 2113951C49 CAP,FXD,51PF,+1%,-
1%,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C1107 2113951C08 CAP,FXD,.8PF,.05PF+/-
,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX
C1109 2113951C49 CAP,FXD,51PF,+1%,-
1%,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C1110 2113951C34 CAP,FXD,10PF,+1%,-
1%,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C1111 2113951C39 CAP,FXD,20PF,+1%,-
1%,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C1113 2113946K02 CAP,CHIP,.1UF,+80%,-
20%,16V-DC,0402,Y5V,-
30DEG CMIN,85DEG
CMAX
C1114 2113944C45 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX
C1116 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1117 2113946K02 CAP,CHIP,.1UF,+80%,-
20%,16V-DC,0402,Y5V,-
30DEG CMIN,85DEG
CMAX
C1119 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1120 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1121 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
Circuit
Ref
Motorola Part
No
Description
C1200 2113945C02 CAP,CHIP,.01UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMA
C1201 2113946K02 CAP,CHIP,.1UF,+80%,-
20%,16V-DC,0402,Y5V,-
30DEG CMIN,85DEG
CMAX
C1202 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1203 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1204 2115153H03 CAP,CER CHIP,1PF,.1PF+/
-,+.1%,-.1%,50V-
DC,0402,C0G
C1205 2113944A52 CAP,CHIP,1000PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1206 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1230 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1300 2115153H49 CAP,FXD,47PF,+1%,-
1%,50V-DC,0402,C0G
C1301 2115153H25 CAP,CERAMIC
CHIP,8.2PF,.1PF+/-,+.1%,-
.1%,50V-
DC,0402,C0G,CAP,
C1302 2115153H39 CAP,FXD,18PF,50V-
DC,0402,C0G
C1303 2115153H06 CAP,FXD,1.3PF,.1PF+/-
,50V-DC,0402,C0G
C1304 2115153H24 CAP,CER
CHIP,7.5PF,.1PF+/-,+.1%,-
.1%,50V-
DC,0402,C0G,CAP, CERA
Circuit
Ref
Motorola Part
No
Description
C1305 2115153H17 CAP,FXD,3.9PF,.1PF+/-
,50V-DC,0402,C0G,CAP,
CERAMIC, COG
C1306 2115153H27 CAP,FXD,10PF,.1PF+/-
,+1%,-1%,50V-
DC,0402,C0G,CAP,
CERAMIC, COG
C1307 2185957Y47 CAP,.5PF,CAP,NP0,0.5 PF
+/-.05PF,200V,0402
C1308 2115153H20 CAP,FXD,5.1PF,.1PF+/-
,+2%,-2%,50V-
DC,0402,C0G,CAP,
CERAMIC, CO
C1309 2115153H16 CAP,CERAMIC
CHIP,3.6PF,.1PF+/-,+.1%,-
.1%,50V-
DC,0402,C0G,CAP,
C1310 2115153H27 CAP,FXD,10PF,.1PF+/-
,+1%,-1%,50V-
DC,0402,C0G,CAP,
CERAMIC, COG
C1311 2115153H17 CAP,FXD,3.9PF,.1PF+/-
,50V-DC,0402,C0G,CAP,
CERAMIC, COG
C1312 2115153H20 CAP,FXD,5.1PF,.1PF+/-
,+2%,-2%,50V-
DC,0402,C0G,CAP,
CERAMIC, CO
C1313 2115153H22 CAP,CERAMIC
CHIP,6.2PF,.1PF+/-,+.1%,-
.1%,50V-
DC,0402,C0G,CAP,
C1314 2115153H41 CAP,FXD,22PF,+1%,-
1%,50V-
DC,0402,C0G,CAP,
CERAMIC, COG
C1315 2113944A44 CAP,CHIP,220PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C1400 2113901A23 CAP,CHIP,5.6PF,.5PF+/-
,200V-DC,0805,-55DEG
CMIN,125DEG CMAX
C1403 2113901A11 CAP,CHIP,2PF,.25PF+/-
,200V-DC,0805,-55DEG
CMIN,125DEG CMAX
Circuit
Ref
Motorola Part
No
Description
To Next Page
