Introduction 2-7
2.1.6 Service Aids
Table 2-4 lists the service aids recommended for working on the Base Station/Repeater (BR). While
all of these items are available from Motorola, most are standard workshop equipment items, and
any equivalent item capable of the same performance may be substituted for the item listed.
Table 2-4 Service Aids
Motorola
Part Number
Schroff Part
number
Description Application
CLN8665A – Standard Type "A" to Type
"B" USB Programming
cable
Connects the Base Station/Repeater’s front
connector to a USB port for programming,
testing and alignment.
HSN1006 – Speaker To listen to any active audible alarms
Note : Use speaker type HSN1000 (older
model) or HSN1006 via adapter cable Part.No.
0185180U01.
3083191X02 – RJ-45 to BNC cable /
Receiver Audio Test Cable
Connects the external speaker RJ-45 jack to
the Oscilloscope input BNC connector.
GMMN4063 – Microphone To transmit voice by connecting it to
microphone connector on SCM.
Note : Use microphone type GMN6147 (older
model) or GMMN4063.
0185180U01 – Speaker adapter cable To connect the speaker to speaker connector
on SCM.
RVN5115 – Customer Programming
Software (CPS) Package
(Includes CPS, Air Tracer,
Tuner, Radio Diagnostic
and Control (RDAC))
Program customer option and channel data.
– 23021653 Extender Card To power up the cluster module (Exciter,
Receiver, Station Control Module) external from
the MTR3000 Base Station/Repeater (BR).
6683334X01 – Option Card tool To pull the option boards (e.g. Wireline
Interface Board or the Auxiliary I/O Board).
