4.6 Controller Parts List (UHF)
Circuit Ref
Motorola Part
No
Description
* PC512F00W000
010000
MTR3000 FPGA
FIRMWARE
C1000M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1001M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1002M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1003M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1004M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1005M1 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1006M1 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1007M1 2113956C35 CAP,FXD,4.7UF,+10%,-
10%,16V-DC,0805,X5R,-
55DEG CMIN,85DEG
CMAX
C1008M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1009M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1010M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1011M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1012M1 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1013M1 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1014M1 2113956C35 CAP,FXD,4.7UF,+10%,-
10%,16V-DC,0805,X5R,-
55DEG CMIN,85DEG
CMAX
C1015M1 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1016M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1017M1 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1018M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1019M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1020M1 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1021M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1022M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1023M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1024M1 2113944A40 CAP CER CHP 100.0PF
50V 5%
Circuit Ref
Motorola Part
No
Description
C1025M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1026M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1027M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1028M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1029M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1030M1 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1031M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1032M1 2113946S35 CAP CER CHP 1.0UF 16V
10%
C1033M1 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1034M1 2113946D05 CAP,CHIP,2.2UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C1035M1 2113946S35 CAP CER CHP 1.0UF 16V
10%
C1036M1 2113946S35 CAP CER CHP 1.0UF 16V
10%
C1037M1 2113946D05 CAP,CHIP,2.2UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C1038M1 2113944A01 CAP CER CHP 1.1PF 50V
+/- 0.25PF
C1039M1 2113944A01 CAP CER CHP 1.1PF 50V
+/- 0.25PF
Circuit Ref
Motorola Part
No
Description
C1043M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1044M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1045M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1046M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1047M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1048M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1049M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1050M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1051M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1052M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1053M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1054M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1055M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1056M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1057M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1058M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1059M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1060M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1061M1 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
Circuit Ref
Motorola Part
No
Description
