Motorola MTR3000 User Manual

4-33
4.3.16 Calibration Procedure
1. Remove the base station/repeater’s front bezel from its chassis.
2. Power-up the base station/repeater and allow it to boot up normally.
3. Plug in the External Reference to J3008M7 on the SCM. The SCM accepts 5/10 MHz
Sine/Square wave with amplitude of 3.3 Vpp.
4. Monitor the station reference LED. The LED will stay solid amber to indicate that the
station is locked to external reference and is in alignment process.
5. When the station completes the alignment, the station reference LED will turn solid
green.
6. Power down the base station/repeater and remove the External Reference.
7. Replace the base station/repeater’s front bezel and power-up the base station/repeater.
Note
For the OCXO kit, the controller must be power-up for a minimum of 15 minutes before the
execution of the following calibration procedures.
