Motorola MTR3000 User Manual

Introduction 2-3
DO NOT attempt to disassemble the base station/repeater without first referring to the following
CAUTION statement.
2.1.4 Repair Procedures and Techniques – General
Any rework or repair on Environmentally Preferred Products must be done using the appropriate
lead-free solder wire and lead-free solder paste as stated in the following table:
This station contains static-sensitive devices. Do not open the base station/repeater
unless you are properly grounded. Take the following precautions when working on
this unit:
• Store and transport all CMOS devices in conductive material so
that all exposed leads are shorted together. Do not insert CMOS
devices into conventional plastic “snow” trays used for storage
and transportation of other semiconductor devices.
• Ground the working surface of the service bench to protect the
CMOS device. We recommend using a wrist strap, two ground
cords, a table mat, and a floor mat.
• Wear a conductive wrist strap in series with a 100k resistor to
ground (replacement wrist straps that connect to the bench top
covering can be ordered using the Motorola part number
4280385A59).
• Do not wear nylon clothing while handling CMOS devices.
• Do not insert or remove CMOS devices with power applied.
Check all power supplies used for testing CMOS devices to be
certain that there are no voltage transients present.
• When straightening CMOS Pins, provide ground straps for the
apparatus used.
• When soldering, use a grounded soldering iron.
• Where possible, handle CMOS devices by the package and not
by the leads. Prior to touching the unit, touch an electrical ground
to remove any static charge that you may have accumulated. The
package and substrate may be electrically common. If so, the
reaction of a discharge to the case would cause the same
damage as touching the leads.
Note
The Motorola MOTOTRBO
TM
MTR3000 Base Station/Repeater system and its subsystems
have been created in compliance with the environmental goals of the European Union’s
Restriction of Hazardous Substances (RoHS) and the Waste Electrical and Electronic
Equipment (WEEE) Directive 2002/96/EC as well as Motorola’s corporate goals to
minimize environmental impact of its products.
This Motorola policy is reflected throughout the entire design, procurement, assembly, and
packaging process.
In support of these efforts to provide environmentally-responsible products, please comply
with the information in the following sections regarding any rework or repair on RoHS-
compliant products.
