Motorola MTR3000 User Manual

3-62 Power Amplifier Parts List (UHF) – CLE6219
3.12 Power Amplifier Parts List
(UHF) – CLE6219
Circuit
Ref
Motorola Part
No
Description
* 1010041C20 SOLDER PASTE(SN62/
PB36/AG2)
C6010 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6013 2113944C49 CAP CER CHP 680.OPF
50V 5
C6014 2113944C47 CAP CER CHP 150.0PF
50V 5%
C6015 2385169Y04 CAP ALU LYT 330UF 35V
20%
C6020 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6023 2113944C49 CAP CER CHP 680.OPF
50V 5
C6024 2113944C47 CAP CER CHP 150.0PF
50V 5%
C6025 2385169Y04 CAP ALU LYT 330UF 35V
20%
C6051 2113946F05 CAP,CHIP,10UF,+10%,-
10%,6.3V-DC,0805,X5R,-
55DEG CMIN,85DEG
CMAX
C6061 2113946F05 CAP,CHIP,10UF,+10%,-
10%,6.3V-DC,0805,X5R,-
55DEG CMIN,85DEG
CMAX
C6100 2113944C28 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C6101 2113944C28 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C6102 2113944C28 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C6103 2113944C28 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C6104 2113944C28 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C6105 2113944C28 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C6106 2113944C28 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C6107 2113944C28 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C6110 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6111 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6112 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6113 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6114 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6115 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6116 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6117 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6132 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6133 2113945D04 CAP CER CHP 100,000PF
25V 10%
Circuit
Ref
Motorola Part
No
Description
C6160 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6161 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6162 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6163 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6164 2113945D04 CAP CER CHP 100,000PF
25V 10%
C6165 2113945D04 CAP CER CHP 100,000PF
25V 10%
C6166 2113945D04 CAP CER CHP 100,000PF
25V 10%
C6167 2113945D04 CAP CER CHP 100,000PF
25V 10%
C6168 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6171 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6172 2113945D04 CAP CER CHP 100,000PF
25V 10%
C6190 2113944C28 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C6191 2113944C28 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C6192 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
Circuit
Ref
Motorola Part
No
Description
C6193 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6241 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6242 2113945D04 CAP CER CHP 100,000PF
25V 10%
C6250 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6251 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6252 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6253 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6254 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6255 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6256 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6257 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6258 2113944C93 CAP,FXD,430PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
Circuit
Ref
Motorola Part
No
Description
