Motorola MTR3000 User Manual

Power Amplifier Parts List (UHF) – CLE6218 3-61
3.11 Power Amplifier Parts List
(UHF) – CLE6218
Circuit
Ref
Motorola Part
No
Description
C8001 2113951D14 CAP,FXD,1.5PF,.05PF,250
V-DC,0805,C0G,-55DEG
CMIN,125DEG CMA
C8002 2113951D03 CAP,FXD,.3PF,.05PF,250V
-DC,0805,C0G,-55DEG
CMIN,125DEG CMAX
C8003 2113951D10 CAP,FXD,1PF,.05PF,250V-
DC,0805,C0G,-55DEG
CMIN,125DEG CMAX
C8004 2113951D03 CAP,FXD,.3PF,.05PF,250V
-DC,0805,C0G,-55DEG
CMIN,125DEG CMAX
C8005 2113951D10 CAP,FXD,1PF,.05PF,250V-
DC,0805,C0G,-55DEG
CMIN,125DEG CMAX
C8006 2113951D03 CAP,FXD,.3PF,.05PF,250V
-DC,0805,C0G,-55DEG
CMIN,125DEG CMAX
C8008 2113951D03 CAP,FXD,.3PF,.05PF,250V
-DC,0805,C0G,-55DEG
CMIN,125DEG CMAX
C8009 2113951D20 CAP,FXD,2.7PF,.05PF,250
V-DC,0805,C0G,-55DEG
CMIN,125DEG CMA
C8010 2113951D17 CAP,FXD,2PF,.05PF,250V-
DC,0805,C0G,-55DEG
CMIN,125DEG CMAX
C8012 2113951D22 CAP,FXD,3.3PF,.05PF,250
V-DC,0805,C0G,-55DEG
CMIN,125DEG CMA
C8013 2113951B33 CAP NPO 9.10PF 5%
250V HI FREQ
C8021 2113951B56 CAP NPO HIGH FREQ 100
5V
C8023 2113951B33 CAP NPO 9.10PF 5%
250V HI FREQ
C8031 2113951B56 CAP NPO HIGH FREQ 100
5V
CR8000 4885046Y01 DIODE RF SCHOTTKY
PB-FREE
CR8001 4885046Y01 DIODE RF SCHOTTKY
PB-FREE
L8000 2485873L01 ENCAPSULATED AIR
WOUND COIL
L8001 2485873L01 ENCAPSULATED AIR
WOUND COIL
L8002 2485873L01 ENCAPSULATED AIR
WOUND COIL
L8003 2485873L01 ENCAPSULATED AIR
WOUND COIL
L8004 2471604H03 SMD AIR WOUND COIL,
422NH, 5.0%
L8010 2414017N09 IDCTR,FXD,5.6NH,5.35%,
600MA,.2Ω,CER,10
Q,3GHZ SRF,SM,0603
L8011 2414017N09 IDCTR,FXD,5.6NH,5.35%,
600MA,.2Ω,CER,10
Q,3GHZ SRF,SM,0603
L8012 2414017N26 IDCTR,CHIP,150NH,5%,20
0MA,2.4Ω,CER,11
Q,550MHZ SRF,SM,0603
L8020 2414017N09 IDCTR,FXD,5.6NH,5.35%,
600MA,.2Ω,CER,10
Q,3GHZ SRF,SM,0603
L8021 2414017N09 IDCTR,FXD,5.6NH,5.35%,
600MA,.2Ω,CER,10
Q,3GHZ SRF,SM,0603
L8022 2414017N26 IDCTR,CHIP,150NH,5%,20
0MA,2.4Ω,CER,11
Q,550MHZ SRF,SM,0603
PWB 84009274001 PA OUTPUT PCB
403– 470 MHZ
R8010 0613959B95 CER CHIP RES 95.3Ω 1%
1210
R8011 0613959B95 CER CHIP RES 95.3Ω 1%
1210
R8012 0613952C39 CER CHIP RES 249Ω 1%
0603
R8013 0613952B66 CER CHIP RES 47.5Ω 1%
0603
R8014 0613952E55 CER CHIP RES 36.5KΩ
1% 0603
Circuit
Ref
Motorola Part
No
Description
R8020 0613959B95 CER CHIP RES 95.3Ω 1%
1210
R8021 0613959B95 CER CHIP RES 95.3Ω 1%
1210
R8022 0613952C39 CER CHIP RES 249Ω 1%
0603
R8023 0613952B66 CER CHIP RES 47.5Ω 1%
0603
R8024 0613952E30 CER CHIP RES 20.0KΩ
1% 0603
