1-6 Specifications
1.3 Specifications
Table 1-3 shows the specifications of the MTR3000 Base Station/Repeater.
Table 1-2 MTR2000 MOTOTRBO Digital Upgrade Frequency Ranges and Power Levels
Frequency
Band
Bandwidth Power Level
UHF 403–435 MHz 25–100 W
435–470 MHz 25–100 W
Table 1-3 MTR3000 Base Station/Repeater General Specifications (All Bands)
Parameter Specifications
Number of Channels 16
Frequency Generation Synthesized
Input Voltage AC 85–264 VAC (47–63 Hz)
Input Voltage DC 28.6 VDC (25.7–30.7 VDC full rated output power)
Power Supply Type Switching
Station Weight 40 lbs (19 kg)
Temperature Range -30°C to +60°C (-22°F to +140°F)
Antenna Connectors Tx/Rx N-Type
Modes of Operation Half-Duplex / Duplex
Rack Units 3
Height 5.25” (133 mm)
Width 19” (483 mm)
Depth 16.5” (419 mm)
Industry Canada
• IC certification / registration number
• IC model number
• Tx / Rx Frequency range
109AB-T3000
T3000-UHF R1
406.1–430 MHz, 450–470 MHz
