Motorola MTR3000 User Manual

Exciter Parts List (UHF) – CTE4004 7-37
7.5 Exciter Parts List (UHF) –
CTE4004
Circuit
Ref
Motorola Part
No
Description
* 1085674C03 PASTE/NC-SMQ230
* 2683006X02 COVER, TX VCO SHIELD
* 84009272002 MTR3000 EXCITER
C4000 2113945B02 CAP CER CHP 10,000PF
25V 10%
C4001 2113946K02 CAP CER CHP 0.10UF
16V
C4002 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4003 2113946K02 CAP CER CHP 0.10UF
16V
C4004 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4005 2113946K02 CAP CER CHP 0.10UF
16V
C4006 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4007 2113946K02 CAP CER CHP 0.10UF
16V
C4008 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4009 2113946K02 CAP CER CHP 0.10UF
16V
C4010 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4011 2113946K02 CAP CER CHP 0.10UF
16V
C4012 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4013 2113946K02 CAP CER CHP 0.10UF
16V
C4014 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4015 2113946A01 CAP CER CHP 0.015UF
16V 10%
C4016 2113946J02 CAP CER CHP 4.7UF 16V
10%
C4100 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4101 2113945B02 CAP CER CHP 10,000PF
25V 10%
C4102 2113946K02 CAP CER CHP 0.10UF
16V
C4103 2113946K02 CAP CER CHP 0.10UF
16V
C4104 2113944A27 CAP CER CHP 15.0PF
50V 5%
C4105 2113946K02 CAP CER CHP 0.10UF
16V
C4106 2113944A31 CAP CER CHP 33.0PF
50V 5%
C4107 2113944A43 CAP CER CHP 180.0PF
50V 5%
C4200 2113944A25 CAP CER CHP 10.0PF
50V +/- 0.5PF
C4301 2113945B02 CAP CER CHP 10,000PF
25V 10%
C4302 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4304 2113955D01 CAP,FXD,1UF,+10%,-
10%,100V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C4305 2313960F01 CAP,FXD,10UF,+10%,-
10%,16V-DC,SM,-55DEG
CMIN,125DEG
CMAX,247MA
C4306 2113946K02 CAP CER CHP 0.10UF
16V
C4307 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4309 2113945C02 CAP CER CHP 10,000PF
50V 10%
C4310 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4311 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
Circuit
Ref
Motorola Part
No
Description
C4312 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C4314 2313960E32 CAP,FXD,10UF,+10%,-
10%,35V-DC,SM,-55DEG
CMIN,125DEG
CMAX,262MA
C4315 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C4316 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4318 2113945B02 CAP CER CHP 10,000PF
25V 10%
C4319 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4321 2113945D04 CAP CER CHP 100,000PF
25V 10%
C4322 2313960F01 CAP,FXD,10UF,+10%,-
10%,16V-DC,SM,-55DEG
CMIN,125DEG
CMAX,247MA
C4323 2113946K02 CAP CER CHP 0.10UF
16V
C4324 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4325 2313960F01 CAP,FXD,10UF,+10%,-
10%,16V-DC,SM,-55DEG
CMIN,125DEG
CMAX,247MA
C4326 2113946K02 CAP CER CHP 0.10UF
16V
C4327 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4401 2113946K02 CAP CER CHP 0.10UF
16V
C4402 2113946K02 CAP CER CHP 0.10UF
16V
C4403 2113946K02 CAP CER CHP 0.10UF
16V
Circuit
Ref
Motorola Part
No
Description
C4404 2113946K02 CAP CER CHP 0.10UF
16V
C4405 2113945B02 CAP CER CHP 10,000PF
25V 10%
C4406 2113946K02 CAP CER CHP 0.10UF
16V
C4407 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C4408 2113944A25 CAP CER CHP 10.0PF
50V +/- 0.5PF
C4409 2113946B04 CAP CER CHP 0.10UF
10V 10%
C4419 2113946K02 CAP CER CHP 0.10UF
16V
C4420 2113945B02 CAP CER CHP 10,000PF
25V 10%
C4421 2113946K02 CAP CER CHP 0.10UF
16V
C4422 2113945B02 CAP CER CHP 10,000PF
25V 10%
C4501 2113944A42 CAP CER CHP 150.0PF
50V 5%
C4502 2113945C02 CAP CER CHP 10,000PF
50V 10%
C4503 2385170Y08 CAP AL LYTIC 330UF 25V
20% PB-FREE
C4504 2113945B02 CAP CER CHP 10,000PF
25V 10%
C4505 2113945D04 CAP CER CHP 100,000PF
25V 10%
C4506 2113944A42 CAP CER CHP 150.0PF
50V 5%
C4507 2113945D04 CAP CER CHP 100,000PF
25V 10%
C4510 2113945D04 CAP CER CHP 100,000PF
25V 10%
C4512 2113945C04 CAP CER CHP 22,000PF
50V 10%
C4513 2113944A42 CAP CER CHP 150.0PF
50V 5%
Circuit
Ref
Motorola Part
No
Description
