3-50 Power Amplifier Parts List (UHF) – CLE6215
3.8 Power Amplifier Parts List
(UHF) – CLE6215
Circuit
Ref
Motorola Part
No
Description
C2030 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2031 2113945G45 CAP,FXD,.01UF,+5%,-
5%,50V-DC,0805,X7R,-
55DEG CMIN,125DEG
CMAX,P
C2032 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2033 2113945G45 CAP,FXD,.01UF,+5%,-
5%,50V-DC,0805,X7R,-
55DEG CMIN,125DEG
CMAX,P
C2034 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2035 2113945G45 CAP,FXD,.01UF,+5%,-
5%,50V-DC,0805,X7R,-
55DEG CMIN,125DEG
CMAX,P
C2036 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2037 2113945G45 CAP,FXD,.01UF,+5%,-
5%,50V-DC,0805,X7R,-
55DEG CMIN,125DEG
CMAX,P
C2038 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2039 2113945G45 CAP,FXD,.01UF,+5%,-
5%,50V-DC,0805,X7R,-
55DEG CMIN,125DEG
CMAX,P
C2040 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2041 2113945G45 CAP,FXD,.01UF,+5%,-
5%,50V-DC,0805,X7R,-
55DEG CMIN,125DEG
CMAX,P
C2100 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2101 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2102 2113944C04 CAP CER CHP 330.0PF
50V 5%
C2103 2113945C02 CAP CER CHP 10,000PF
50V 10%
C2200 2113945C02 CAP CER CHP 10,000PF
50V 10%
C2201 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2304 2113944C46 CAP CER CHP 120.0PF
50V 5%
C2306 2113945C02 CAP CER CHP 10,000PF
50V 10%
C2307 2113944C30 CAP CER CHP 10.0PF
50V +/- 0.5PF
C2308 2113944C47 CAP CER CHP 150.0PF
50V 5%
C2309 2113945C02 CAP CER CHP 10,000PF
50V 10%
C2310 2113951A18 CAP NPO 2.20PF +/-.1PF
250V HI FREQ
C2311 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2316 2113944C46 CAP CER CHP 120.0PF
50V 5%
C2318 2113945C02 CAP CER CHP 10,000PF
50V 10%
C2319 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2321 2113944C47 CAP CER CHP 150.0PF
50V 5%
C2322 2113944C30 CAP CER CHP 10.0PF
50V +/- 0.5PF
C2323 2113945C02 CAP CER CHP 10,000PF
50V 10%
C2325 2113945C02 CAP CER CHP 10,000PF
50V 10%
C2326 2113951A22 CAP NPO 3.30PF +/-.1PF
250V HI FREQ
C2327 2113945C02 CAP CER CHP 10,000PF
50V 10%
Circuit
Ref
Motorola Part
No
Description
C2400 2113945C02 CAP CER CHP 10,000PF
50V 10%
C2401 2113944F05 CAP,CHIP,470PF,+5%,-
5%,50V-DC,0805,C0G,-
55DEG CMIN,125DEG
CMAX
C2402 2113945C02 CAP CER CHP 10,000PF
50V 10%
C2404 2113945C02 CAP CER CHP 10,000PF
50V 10%
C2406 2113945C02 CAP CER CHP 10,000PF
50V 10%
C2407 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2408 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2409 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2500 2113955E11 CAP,FXD,1UF,+10%,-
10%,50V-DC,X7R,-55DEG
CMIN,125DEG CMAX,PB-
FR
C2501 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2502 2113945C02 CAP CER CHP 10,000PF
50V 10%
C2503 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2504 2113955E11 CAP,FXD,1UF,+10%,-
10%,50V-DC,X7R,-55DEG
CMIN,125DEG CMAX,PB-
FR
C2506 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2507 2113944C45 CAP CER CHP 100.0PF
50V 5%
C4210 2113944C45 CAP CER CHP 100.0PF
50V 5%
C4216 2113944C45 CAP CER CHP 100.0PF
50V 5%
C4227 2113944C45 CAP CER CHP 100.0PF
50V 5%
Circuit
Ref
Motorola Part
No
Description
C4228 2113944C45 CAP CER CHP 100.0PF
50V 5%
C4243 2113944C45 CAP CER CHP 100.0PF
50V 5%
C4249 2113944C45 CAP CER CHP 100.0PF
50V 5%
C4257 2113944C45 CAP CER CHP 100.0PF
50V 5%
C4258 2113944C45 CAP CER CHP 100.0PF
50V 5%
C4273 2113944C45 CAP CER CHP 100.0PF
50V 5%
C4279 2113944C45 CAP CER CHP 100.0PF
50V 5%
C4310 2113951B56 CAP NPO HIGH FREQ 100
+/- 5V
C4313 2113944C37 CAP CER CHP 39.0PF
50V 5%
C4314 2185457Y01 CAP CHIP CER 10UF 35V
W18
C4338 2113951A56 CAP NPO 100.0PF +/-5%
250V HI FREQ
C4340 2113951B48 CAP NPO HIGH FREQ
47.0 +/- 5% 250V
C4341 2113951B37 CAP NPO 15.0PF +/- 5%
250V HI FREQ
C4343 2113945C13 CAP CER CHP 1000PF
50V 10%
C4344 2113951B52 CAP NPO HIGH FREQ
68.0 +/- 5% 250V
C4360 2113951C19 CAP,FXD,2.4PF,.05PF+/-
,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMA
C4361 2113951C19 CAP,FXD,2.4PF,.05PF+/-
,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMA
C4362 2113951C36 CAP,FXD,12PF,+1%,-
1%,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
Circuit
Ref
Motorola Part
No
Description
To Next Page
