Motorola MTR3000 User Manual

Power Amplifier Parts List (UHF) – CLE6215 3-51
C4363 2113951C36 CAP,FXD,12PF,+1%,-
1%,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C4370 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4371 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4372 2113951B32 CAP NPO 8.20PF +/- 5%
250V HI FREQ
C4373 2113951B32 CAP NPO 8.20PF +/- 5%
250V HI FREQ
C4374 2113951B38 CAP NPO 18.0PF +/- 5%
250V HI FREQ
C4375 2113951B38 CAP NPO 18.0PF +/- 5%
250V HI FREQ
C4380 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4381 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4382 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4383 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4390 2113951B28 CAP NPO 5.60PF +/-
0.25PF 250V HI-F
C4391 2113951B56 CAP NPO HIGH FREQ 100
+/- 5V
C4392 2113951B56 CAP NPO HIGH FREQ 100
+/- 5V
C4410 2113951B56 CAP NPO HIGH FREQ 100
+/- 5V
C4413 2113944C37 CAP CER CHP 39.0PF
50V 5%
C4414 2185457Y01 CAP CHIP CER 10UF 35V
W18
C4438 2113951A56 CAP NPO 100.0PF +/-5%
250V HI FREQ
C4440 2113951B48 CAP NPO HIGH FREQ
47.0 +/- 5% 250V
Circuit
Ref
Motorola Part
No
Description
C4441 2113951B37 CAP NPO 15.0PF +/- 5%
250V HI FREQ
C4443 2113945C13 CAP CER CHP 1000PF
50V 10%
C4444 2113951B52 CAP NPO HIGH FREQ
68.0 +/- 5% 250V
C4460 2113951C19 CAP,FXD,2.4PF,.05PF+/-
,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMA
C4461 2113951C19 CAP,FXD,2.4PF,.05PF+/-
,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMA
C4462 2113951C36 CAP,FXD,12PF,+1%,-
1%,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C4463 2113951C36 CAP,FXD,12PF,+1%,-
1%,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C4470 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4471 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4472 2113951B32 CAP NPO 8.20PF +/- 5%
250V HI FREQ
C4473 2113951B32 CAP NPO 8.20PF +/- 5%
250V HI FREQ
C4474 2113951B38 CAP NPO 18.0PF +/- 5%
250V HI FREQ
C4475 2113951B38 CAP NPO 18.0PF +/- 5%
250V HI FREQ
C4480 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4481 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4482 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4483 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
Circuit
Ref
Motorola Part
No
Description
C4490 2113951B28 CAP NPO 5.60PF +/-
0.25PF 250V HI-F
C4491 2113951B56 CAP NPO HIGH FREQ 100
+/- 5V
C4492 2113951B56 CAP NPO HIGH FREQ 100
+/- 5V
C4510 2113951B56 CAP NPO HIGH FREQ 100
+/- 5V
C4513 2113944C37 CAP CER CHP 39.0PF
50V 5%
C4514 2185457Y01 CAP CHIP CER 10UF 35V
W18
C4538 2113951A56 CAP NPO 100.0PF +/-5%
250V HI FREQ
C4540 2113951B48 CAP NPO HIGH FREQ
47.0 +/- 5% 250V
C4541 2113951B37 CAP NPO 15.0PF +/- 5%
250V HI FREQ
C4543 2113945C13 CAP CER CHP 1000PF
50V 10%
C4544 2113951B52 CAP NPO HIGH FREQ
68.0 +/- 5% 250V
C4560 2113951C19 CAP,FXD,2.4PF,.05PF+/-
,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMA
C4561 2113951C19 CAP,FXD,2.4PF,.05PF+/-
,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMA
C4562 2113951C36 CAP,FXD,12PF,+1%,-
1%,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C4563 2113951C36 CAP,FXD,12PF,+1%,-
1%,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C4570 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4571 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
Circuit
Ref
Motorola Part
No
Description
C4572 2113951B32 CAP NPO 8.20PF +/- 5%
250V HI FREQ
C4573 2113951B32 CAP NPO 8.20PF +/- 5%
250V HI FREQ
C4574 2113951B38 CAP NPO 18.0PF +/- 5%
250V HI FREQ
C4575 2113951B38 CAP NPO 18.0PF +/- 5%
250V HI FREQ
C4580 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4581 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4582 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4583 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4590 2113951B28 CAP NPO 5.60PF +/-
0.25PF 250V HI-F
C4591 2113951B56 CAP NPO HIGH FREQ 100
+/- 5V
C4592 2113951B56 CAP NPO HIGH FREQ 100
+/- 5V
C4610 2113951B56 CAP NPO HIGH FREQ 100
+/- 5V
C4613 2113944C37 CAP CER CHP 39.0PF
50V 5%
C4614 2185457Y01 CAP CHIP CER 10UF 35V
W18
C4638 2113951A56 CAP NPO 100.0PF +/-5%
250V HI FREQ
C4640 2113951B48 CAP NPO HIGH FREQ
47.0 +/- 5% 250V
C4641 2113951B37 CAP NPO 15.0PF +/- 5%
250V HI FREQ
C4643 2113945C13 CAP CER CHP 1000PF
50V 10%
C4644 2113951B52 CAP NPO HIGH FREQ
68.0 +/- 5% 250V
Circuit
Ref
Motorola Part
No
Description
