3-52 Power Amplifier Parts List (UHF) – CLE6215
C4660 2113951C19 CAP,FXD,2.4PF,.05PF+/-
,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMA
C4661 2113951C19 CAP,FXD,2.4PF,.05PF+/-
,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMA
C4662 2113951C36 CAP,FXD,12PF,+1%,-
1%,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C4663 2113951C36 CAP,FXD,12PF,+1%,-
1%,250V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C4670 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4671 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4672 2113951B32 CAP NPO 8.20PF +/- 5%
250V HI FREQ
C4673 2113951B32 CAP NPO 8.20PF +/- 5%
250V HI FREQ
C4674 2113951B38 CAP NPO 18.0PF +/- 5%
250V HI FREQ
C4675 2113951B38 CAP NPO 18.0PF +/- 5%
250V HI FREQ
C4680 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4681 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4682 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4683 2113951B31 CAP NPO 7.50PF +/- 5%
250V HI FREQ
C4690 2113951B28 CAP NPO 5.60PF +/-
0.25PF 250V HI-F
C4691 2113951B56 CAP NPO HIGH FREQ 100
+/- 5V
C4692 2113951B56 CAP NPO HIGH FREQ 100
+/- 5V
Circuit
Ref
Motorola Part
No
Description
D2200 4813978P05 DIODE ARRAY,SIGNL/
SWG,BAV99,SM,SOT-
23,215MA,70V,.225W,SHT
K,2,PB-
D2202 4813978P05 DIODE ARRAY,SIGNL/
SWG,BAV99,SM,SOT-
23,215MA,70V,.225W,SHT
K,2,PB-
D2204 4813978P05 DIODE ARRAY,SIGNL/
SWG,BAV99,SM,SOT-
23,215MA,70V,.225W,SHT
K,2,PB-
D2206 4813978P05 DIODE ARRAY,SIGNL/
SWG,BAV99,SM,SOT-
23,215MA,70V,.225W,SHT
K,2,PB-
D2208 4813978P05 DIODE ARRAY,SIGNL/
SWG,BAV99,SM,SOT-
23,215MA,70V,.225W,SHT
K,2,PB-
D2400 4813978P05 DIODE ARRAY,SIGNL/
SWG,BAV99,SM,SOT-
23,215MA,70V,.225W,SHT
K,2,PB-
D2402 4813978P05 DIODE ARRAY,SIGNL/
SWG,BAV99,SM,SOT-
23,215MA,70V,.225W,SHT
K,2,PB-
D2404 4813978P05 DIODE ARRAY,SIGNL/
SWG,BAV99,SM,SOT-
23,215MA,70V,.225W,SHT
K,2,PB-
D4220 4813978P05 DIODE ARRAY,SIGNL/
SWG,BAV99,SM,SOT-
23,215MA,70V,.225W,SHT
K,2,PB-
D4221 4813978P05 DIODE ARRAY,SIGNL/
SWG,BAV99,SM,SOT-
23,215MA,70V,.225W,SHT
K,2,PB-
D4250 4813978P05 DIODE ARRAY,SIGNL/
SWG,BAV99,SM,SOT-
23,215MA,70V,.225W,SHT
K,2,PB-
Circuit
Ref
Motorola Part
No
Description
D4251 4813978P05 DIODE ARRAY,SIGNL/
SWG,BAV99,SM,SOT-
23,215MA,70V,.225W,SHT
K,2,PB-
E2300 2485011Y01 INDUCTOR BEAD CHP
PB-FREE
E2301 2485011Y01 INDUCTOR BEAD CHP
PB-FREE
E4311 2485011Y01 INDUCTOR BEAD CHP
PB-FREE
E4411 2485011Y01 INDUCTOR BEAD CHP
PB-FREE
E4511 2485011Y01 INDUCTOR BEAD CHP
PB-FREE
E4611 2485011Y01 INDUCTOR BEAD CHP
PB-FREE
F2100 6585118Y06 FUSE,3A,125V,FAST
ACT,SM
F2400 6585118Y06 FUSE,3A,125V,FAST
ACT,SM
F4316 6585118Y03 FUSE 5A, 125V FAST ACT
W18
F4416 6585118Y03 FUSE 5A, 125V FAST ACT
W18
F4516 6585118Y03 FUSE 5A, 125V FAST ACT
W18
F4616 6585118Y03 FUSE 5A, 125V FAST ACT
W18
J2000 0982492W01 BNC CONN PCB
VERTICAL RECEPT
L2100 2471604H03 SMD AIR WOUND COIL,
422NH, 5.0%
L2101 2416077H21 150NH MIDI SPRING COIL
L2300 2414017N08 IDCTR,FXD,4.7NH,6.38%,
1A,.17Ω,CER,10
Q,3.3GHZ SRF,SM,0603
L2301 2416077H21 150NH MIDI SPRING COIL
L2303 2414017N08 IDCTR,FXD,4.7NH,6.38%,
1A,.17Ω,CER,10
Q,3.3GHZ SRF,SM,0603
Circuit
Ref
Motorola Part
No
Description
L2304 2414017N02 IDCTR,CHIP,1.5NH,1A,.1Ω
,CER,8 Q,6GHZ
SRF,SM,0603,PB-FREE
L2305 2416077H21 150NH MIDI SPRING COIL
M4300 1084806Y05 SOLDER, PREFRM, TR
7.0X4.6 PB
M4400 1084806Y05 SOLDER, PREFRM, TR
7.0X4.6 PB
M4500 1084806Y05 SOLDER, PREFRM, TR
7.0X4.6 PB
M4600 1084806Y05 SOLDER, PREFRM, TR
7.0X4.6 PB
PWB 0180706J22 RF BOARD COIN
ASSEMBLY
Q2100 5185337Y01 IC, HIGH LINEARITY
AMPLIFIER, W18
Q2300 4888606T31 HIGH POWER
DISTRIUBTED
AMPLIFIER
Q2400 4813971A10 XSTR,BIP GP
POWER,BIPLR,NPN,MJD
2955,DPAK,SM,60V,20W,1
0A,2MHZ,P
Q2401 4813973M07 XSTR,BIP GP
SS,NPN,T3904,SM,SOT-
23,SMT,40V,.225W,200MA
,300MHZ
Q2500 4813972M07 PB-FREE,NOT
COMPLETELY ENRICHED
Q4200 4813972M07 PB-FREE,NOT
COMPLETELY ENRICHED
Q4201 4813970M64 XSTR,FET GP
PWR,MOSFET,P-
CH,ENHN,SM,SOT-23,-
20V,.225W,PB-FRE
Q4300 4878031A01 RF POWER FET,
MRFE6S9045NR1
Q4400 4878031A01 RF POWER FET,
MRFE6S9045NR1
Q4500 4878031A01 RF POWER FET,
MRFE6S9045NR1
Circuit
Ref
Motorola Part
No
Description
