Motorola MTR3000 User Manual

Power Amplifier Parts List (UHF) – CLE6215 3-53
Q4600 4878031A01 RF POWER FET,
MRFE6S9045NR1
R2026 0613952D64 CER CHIP RES 4530Ω 1%
0603
R2100 0613952C62 CER CHIP RES 432Ω 1%
0603
R2101 0613952B07 CER CHIP RES 11.5Ω 1%
0603
R2102 0613952C62 CER CHIP RES 432Ω 1%
0603
R2103 0613959S81 CER CHIP RESΩ 1% 2512
R2104 0613959S81 CER CHIP RESΩ 1% 2512
R2105 0613952C46 CER CHIP RES 294Ω 1%
0603
R2106 0613952B25 CER CHIP RES 17.8Ω 1%
0603
R2107 0613952C46 CER CHIP RES 294Ω 1%
0603
R2200 0613952C68 CER CHIP RES 499Ω 1%
0603
R2201 0613952C68 CER CHIP RES 499Ω 1%
0603
R2202 0613952C66 CER CHIP RES 475Ω 1%
0603
R2203 0613952D01 CER CHIP RES 1000Ω 1%
0603
R2204 0613952B68 CER CHIP RES 49.9Ω 1%
0603
R2205 0613952B68 CER CHIP RES 49.9Ω 1%
0603
R2206 0613952C72 CER CHIP RES 549Ω 1%
0603
R2207 0613952C66 CER CHIP RES 475Ω 1%
0603
R2208 0613952C46 CER CHIP RES 294Ω 1%
0603
R2210 0613952B85 CER CHIP RES 75.0Ω 1%
0603
R2302 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
Circuit
Ref
Motorola Part
No
Description
R2303 0613952E09 CER CHIP RES 12.1KΩ
1% 0603
R2305 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R2308 0613952E09 CER CHIP RES 12.1KΩ
1% 0603
R2309 0613952B93 CER CHIP RES 90.9Ω 1%
R2310 0613952B93 CER CHIP RES 90.9Ω 1%
R2311 0613952B93 CER CHIP RES 90.9Ω 1%
R2315 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R2317 0613952B62 CER CHIP RES 43.2Ω 1%
R2318 0613952B07 CER CHIP RES 11.5Ω 1%
0603
R2319 0613952B07 CER CHIP RES 11.5Ω 1%
0603
R2320 0613952D24 CER CHIP RES 1740Ω 1%
0603
R2321 0613952D24 CER CHIP RES 1740Ω 1%
0603
R2322 0613952D24 CER CHIP RES 1740Ω 1%
0603
R2323 0613952D24 CER CHIP RES 1740Ω 1%
0603
R2400 0613959S18 CER CHIP RESΩ 1% 2512
R2401 0613958E01 CER CHIP RES 10.0KΩ
1% 0805
R2402 0613958J74 CER CHIP RES 0.0Ω JMP
0805
R2403 0613958E01 CER CHIP RES 10.0KΩ
1% 0805
R2404 0613958E01 CER CHIP RES 10.0KΩ
1% 0805
R2405 0613958N01 CER CHIP RES 1000Ω 1%
R2406 0613958N01 CER CHIP RES 1000Ω 1%
R2407 0613958N01 CER CHIP RES 1000Ω 1%
R2408 0613952D34 CER CHIP RES 2210Ω 1%
0603
Circuit
Ref
Motorola Part
No
Description
R2500 0613952C42 CER CHIP RES 267Ω 1%
0603
R2501 0613952C42 CER CHIP RES 267Ω 1%
0603
R2502 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R2503 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R2504 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R2510 0613952E18 CER CHIP RES 15.0KΩ
1% 0603
R2514 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R4111 06009095002 RES CHIP 3-TERM ALN
50Ω 10W 2% EPP
R4121 06009095002 RES CHIP 3-TERM ALN
50Ω 10W 2% EPP
R4124 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R4131 06009095002 RES CHIP 3-TERM ALN
50Ω 10W 2% EPP
R4211 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R4212 0613952E18 CER CHIP RES 15.0KΩ
1% 0603
R4217 0613952D01 CER CHIP RES 1000Ω 1%
0603
R4220 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R4223 0613959G55 CER CHIP RES 180Ω 5%
1210
R4240 0613952H73 CER CHIP RES 1000Ω 5%
0603
R4241 0613952H73 CER CHIP RES 1000Ω 5%
0603
R4244 0613952H73 CER CHIP RES 1000Ω 5%
0603
R4245 0613952H73 CER CHIP RES 1000Ω 5%
0603
Circuit
Ref
Motorola Part
No
Description
R4246 0613952H66 CER CHIP RES 510Ω 5%
0603
R4250 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R4253 0613959G55 CER CHIP RES 180Ω 5%
1210
R4270 0613952H73 CER CHIP RES 1000Ω 5%
0603
R4271 0613952H73 CER CHIP RES 1000Ω 5%
0603
R4274 0613952H73 CER CHIP RES 1000Ω 5%
0603
R4275 0613952H73 CER CHIP RES 1000Ω 5%
0603
R4276 0613952H66 CER CHIP RES 510Ω 5%
0603
R4280 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R4281 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R4282 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R4283 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R4284 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R4286 0613952E01 CER CHIP RES 10.0KΩ
1% 0603
R4289 0613952D01 CER CHIP RES 1000Ω 1%
0603
R4290 0613952D06 CER CHIP RES 1130Ω 1%
0603
R4291 0613952G67 CER CHIP RES 0.0 +/-
0.050Ω
R4312 0613959B34 CER CHIP RES 22.1Ω 1%
1210
R4315 0685357Y01 RES FIXED CHIP .0100 1
1W EPP
R4333 0613952H95 CER CHIP RES 8200Ω 5%
0603
Circuit
Ref
Motorola Part
No
Description
