Motorola MTR3000 User Manual

4-54 Controller Parts List (UHF)
C1062M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1201M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1202M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1203M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1204M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1205M1 2113946S35 CAP CER CHP 1.0UF 16V
10%
C1206M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1207M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1400M1 2113956E91 CAP,FXD,10UF,+10%,-
10%,16V-DC,1210,X5R,-
55DEG CMIN,85DEG
CMAX,P
C1402M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1403M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1405M1 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1406M1 2113945B02 CAP CER CHP 10,000PF
25V 10%
Circuit Ref
Motorola Part
No
Description
C1407M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1408M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1409M1 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX
C1410M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1411M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1412M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1413M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1414M1 2113946D05 CAP,CHIP,2.2UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C1415M1 2113946D05 CAP,CHIP,2.2UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C1416M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1417M1 2113945A09 CAP CER CHP 1000PF
50V 10%
C1418M1 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1419M1 2113944A40 CAP CER CHP 100.0PF
50V 5%
Circuit Ref
Motorola Part
No
Description
C1420M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1421M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1422M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1423M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1424M1 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1425M1 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1426M1 2113944F81 CAP,FXD,750PF,+5%,-
5%,50V-DC,0805,C0G,-
55DEG CMIN,125DEG
CMAX,P
C1427M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1428M1 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1429M1 2113946S35 CAP CER CHP 1.0UF 16V
10%
C1430M1 2113946S35 CAP CER CHP 1.0UF 16V
10%
C1431M1 2113946D05 CAP,CHIP,2.2UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C1432M1 2113946D05 CAP,CHIP,2.2UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C1433M1 2113946D05 CAP,CHIP,2.2UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
Circuit Ref
Motorola Part
No
Description
C1434M1 2113946D05 CAP,CHIP,2.2UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C1435M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1436M1 2113946D05 CAP,CHIP,2.2UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C1437M1 2113946D05 CAP,CHIP,2.2UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C1438M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1439M1 2113946J03 CAP CER CHP 10.0UF
16V 10%
C1440M1 2113945A05 CAP CER CHP 470PF 50V
10%
C1441M1 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1442M1 2113946J03 CAP CER CHP 10.0UF
16V 10%
C1443M1 2113956E91 CAP,FXD,10UF,+10%,-
10%,16V-DC,1210,X5R,-
55DEG CMIN,85DEG
CMAX,P
C1444M1 2113946B04 CAP CER CHP 0.10UF
10V 10%
C1445M1 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C1446M1 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1447M1 2113956C35 CAP,FXD,4.7UF,+10%,-
10%,16V-DC,0805,X5R,-
55DEG CMIN,85DEG
CMAX
C1449M1 2113946S35 CAP CER CHP 1.0UF 16V
10%
Circuit Ref
Motorola Part
No
Description
