4-74 Controller Parts List (UHF)
R4005M4 0613952N01 CER CHIP RES 10.0KΩ
1% 0402
R4011M4 0613952N01 CER CHIP RES 10.0KΩ
1% 0402
R4018M4 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4019M4 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4022M4 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4024M4 0613952M66 CER CHIP RES 4750Ω 1%
0402
R4030M4 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4031M4 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
R4032M4 0613952R66 CER CHIP RES 0.0 +/-
0.050Ω
T3106M7 2489647C01 XFMR,1:1,SM,10BASE-
T_XFMR, ENET
TRANSFORMER, HALO,
TG110-SO
U1000M1 5102495J13 IC,MICROP,P1710ZZGE,B
GA,,,12MHZ,32BITS
U1001M1 5102495J13 IC,MICROP,P1710ZZGE,B
GA,,,12MHZ,32BITS
U1002M1 0180706J37 IC, FLASH,
PREPROGRAMMED
U1003M1 51012031001 32MB DIE SHRINK DDR
SDRAM IC
U1200M1 5187970L07 IC ADV USB
TRANSCEIVER 3.1X3.1
U1201M1 5171779H01 SPDT ANALOG SWITCH
U1202M1 5188540T01 IC,AND,NC7SZ08,1PER
PKG,SC70,SC70,PB-
FREE
U1203M1 5188540T01 IC,AND,NC7SZ08,1PER
PKG,SC70,SC70,PB-
FREE
U1402M1 5185143E77 IC, MAKO ASIC, CMOS
PWR MGMT
Circuit Ref
Motorola Part
No
Description
U1403M1 5171674H01 OP AMP
U1404M1 5114610F01 500MA LDO 0.8V TO 5.5V
INPUT/OUTPUT
U1406M1 5184790Y04 IC,400MA ADJ VREG
LDO,SOT23
U1600M1 0180706J37 IC, FLASH,
PREPROGRAMMED
U1601M1 51012031001 32MB DIE SHRINK DDR
SDRAM IC
U1800M1 5187970L07 IC ADV USB
TRANSCEIVER 3.1X3.1
U1801M1 5171779H01 SPDT ANALOG SWITCH
U2000M5 5114698D01 IC,FPGA,FTBGA256,SPA
RTAN 3AN FPGA
U2200M5 5114000C01 IC,BFR,8PER
PKG,74VHCT244,3ST,SM,
TSSOP20,PB-FREE
U2201M5 5114000C01 IC,BFR,8PER
PKG,74VHCT244,3ST,SM,
TSSOP20,PB-FREE
U2202M5 5114000C01 IC,BFR,8PER
PKG,74VHCT244,3ST,SM,
TSSOP20,PB-FREE
U2203M5 5114019M13 IC,BFR,8PER
PKG,74LVX244,LOW
VOLATGE,3ST,SM,TSSOP
20,PB-FREE
U2207M5 5114000M42 IC,MONOSTABLE
MULTIVIBRATOR,2PER
PKG,74HC4538,DUAL
PRECISION,SM
U2208M5 5185941F86 IC, 4- BIT BUS
TRANSCEIVER
U2400M6 5115001H02 NL27WZU04DFT2G
INVERTER (EPP)
U2401M6 5185096Y01 12-BIT DAC W OUTPUT
AMPLF W18
U2402M6 5184936Y01 CLOCK BUFFER
U2403M6 5171779H01 SPDT ANALOG SWITCH
U2404M6 5184937Y01 PRECISION
COMPARATOR
Circuit Ref
Motorola Part
No
Description
U2405M6 4813973M07 XSTR,BIP GP
SS,NPN,T3904,SM,SOT-
23,SMT,40V,.225W,200MA
,300MHZ
U2406M6 4813973M07 XSTR,BIP GP
SS,NPN,T3904,SM,SOT-
23,SMT,40V,.225W,200MA
,300MHZ
U2407M6 5185183Y01 HI PERF DUAL CMOS
OPAMP W18
U2600M2 5164852H47 IC, I2C LEVEL
TRANSLATOR
U2601M2 5115368H01 I2C AUDIO ATTENUATOR
U2602M2 5171779H01 SPDT ANALOG SWITCH
U2603M2 5114016A12 IC,OP AMP,4PER
PKG,LVOLT,SM,SO-
14,PB-FREE
U2604M2 5184334Y01 IC HIGH PERFORMANCE
SING SPLY
U2607M2 5171779H01 SPDT ANALOG SWITCH
U2608M2 5171779H01 SPDT ANALOG SWITCH
U2800M2 5184334Y01 IC HIGH PERFORMANCE
SING SPLY
U2802M2 5184334Y01 IC HIGH PERFORMANCE
SING SPLY
U2803M2 5184334Y01 IC HIGH PERFORMANCE
SING SPLY
U3000M7 5114019M05 IC,INVTR,SCHMITT,74LVX
14,6PER
PKG,SM,TSSOP14,PB-
FREE
U3005M7 51009265001 USB 2.0 TO 10/100 USB
CONTROLLER
U3007M7 5175422H01 8-BIT DUAL SUPPLY BUS
TXCVR
U3020M7 5189995T01 IC,XCVR,1PER
PKG,SN74LVC1T45DCKR
G4,LVCMOS,SOT-353/SC-
88A,SC70
Circuit Ref
Motorola Part
No
Description
U3025M7 5189995T01 IC,XCVR,1PER
PKG,SN74LVC1T45DCKR
G4,LVCMOS,SOT-353/SC-
88A,SC70
U3064M7 5184937Y01 PRECISION
COMPARATOR
U3073M7 5189995T01 IC,XCVR,1PER
PKG,SN74LVC1T45DCKR
G4,LVCMOS,SOT-353/SC-
88A,SC70
U3087M7 5109522E84 IC DUAL SCHMITT TRIG
MICRO PAK
U3127M7 5189995T01 IC,XCVR,1PER
PKG,SN74LVC1T45DCKR
G4,LVCMOS,SOT-353/SC-
88A,SC70
U3400M3 5109522E84 IC DUAL SCHMITT TRIG
MICRO PAK
U3401M3 5189995T01 IC,XCVR,1PER
PKG,SN74LVC1T45DCKR
G4,LVCMOS,SOT-353/SC-
88A,SC70
U3403M3 5175422H01 8-BIT DUAL SUPPLY BUS
TXCVR
U3600M3 5185941F86 IC, 4- BIT BUS
TRANSCEIVER
U3601M3 5114019M13 IC,BFR,8PER
PKG,74LVX244,LOW
VOLATGE,3ST,SM,TSSOP
20,PB-FREE
U3602M3 5185941F86 IC, 4- BIT BUS
TRANSCEIVER
U3603M3 5114019M13 IC,BFR,8PER
PKG,74LVX244,LOW
VOLATGE,3ST,SM,TSSOP
20,PB-FREE
U3604M3 5114019M13 IC,BFR,8PER
PKG,74LVX244,LOW
VOLATGE,3ST,SM,TSSOP
20,PB-FREE
U3605M3 5185941F86 IC, 4- BIT BUS
TRANSCEIVER
U3606M3 5115865H01 SINGLE-BIT BUS
TRANSCEIVER
Circuit Ref
Motorola Part
No
Description
