NE-4100 Series User’s Manual Web Console Configuration
6-15
TCP alive check time
Setting Factory Default Necessity
0 to 99 min 7 min Optional
0 min: The TCP connection is not closed due to an idle TCP connection.
1 to 99 min: The module automatically closes the TCP connection if there is no TCP activity for
the given time. After the connection is closed, the module starts listening for another host’s TCP
connection.
Inactivity time
Setting Factory Default Necessity
0 to 65535 ms 0 ms Optional
0 ms: The TCP connection is not closed due to an idle serial line.
0-65535 ms: The module automatically closes the TCP connection if there is no serial data activity
for the given time. After the connection is closed, the module starts listening for another host’s
TCP connection.
This parameter defines the maintenance status as Closed or Listen on the TCP connection. The
connection is closed if there is no incoming or outgoing data through the serial port during the
specific Inactivity time.
If Inactivity time is set to 0, the current TCP connection is maintained until there is a connection
close request. Even with Inactivity time is disabled, the module will still check the connection
status between itself and the remote host by sending “keep alive” packets periodically. If the
remote host does not respond to the packet, it assumes that the connection was closed down
unintentionally. The module will then force the existing TCP connection to close.
ATTENTION
The Inactivity time should be longer than the Force transmit timeout. To prevent the
unintended loss of data due a session getting disconnected, it is strongly recommended that this
value is set large enough so that the intended data transfer is completed.
ATTENTION
Inactivity time is only active when TCP connect on is set to Any Character.
Delimiter 1
Setting Factory Default Necessity
00 to FF “0” for None Optional
Delimiter 2
Setting Factory Default Necessity
00 to FF “0” for None Optional
The Delimiter fields are used to specify a character or 2-character sequence which will act as a
marker to control packing of serial data. By default, no delimiter characters are defined, so the
module transmits data as soon as it is received. When a delimiter character or characters are
defined, the module will hold data in its buffer until it receives the delimiter character or
2-character sequence. When the delimiter is received, the module will pack up the data in its buffer
and send it through the Ethernet port.
