NE-4100 Series User’s Manual Web Console Configuration
6-5
Network Settings
NOTE: “Serial Command Mode” is supported in firmware version 3.0 and above.
You must assign a valid IP address to the module before it will work in your network environment.
Your network system administrator should provide you with an IP address and related settings for
your network. The IP address must be unique within the network; otherwise the module will not
have a valid connection to the network. First time users can refer to Chapter 5 - Initial IP Address
Configuration for more information.
IP configuration
Method Function Definition
Static User defined IP address, Netmask, Gateway.
DHCP
DHCP Server assigned IP address, Netmask, Gateway, DNS, and Time
Server
DHCP/BOOTP
DHCP Server assigned IP address, Netmask, Gateway, DNS, and Time
Server, or BOOTP Server assigned IP address
BOOTP BOOTP Server assigned IP address
IP configuration is a required field. The default setting is Static.
ATTENTION
In Dynamic IP environments, the module will attempt to obtain an IP address from the DHCP or
BOOTP server 3 times at 30-second intervals. The timeout for the first try will be 1 second, the
second try will be to 3 seconds, and the last try will be 5 seconds.
If the DHCP/BOOTP Server is unavailable, the module will use the default IP address
(192.168.127.254), netmask, and gateway settings.
