NE-4100 Series User’s Manual Network Enabler Administrator
7-12
Monitor Functions
Monitor functions allow the monitoring of the selected module’s connection and other basic
settings over the network. Modules are added to the module list using Add Target or Load
Configured COM Port.
Add and Remove Target
Initially, there will be no modules in the Monitor module list. Add Target is used to search for
modules over the network to add to the Monitor module list. Remove Target is used to delete the
selected items from the Monitor module list.
1. Search for the module to add to the Monitor module list by selecting Add Target in the
Monitor context menu. Note that this menu may also be opened by right-clicking Monitor
in the navigation panel.
2. There are three options for adding a module:
y If the module already shows up, you may select it with a check mark and then click OK.
y If the module does not show up, you may do a broadcast search for the module by clicking
Rescan.
y You may manually specify the IP address of the module by selecting Input manually and
entering the address.
