TN-5516/5518 User’s Manual Featured Functions
3-33
"Settings" Items
Redundancy Protocol
Setting Description Factory Default
Turbo Ring This selects the Turbo Ring protocol.
Turbo Ring V2 This selects the Turbo Ring V2 protocol.
RSTP
(IEEE802.1w/1D)
This selects the RSTP protocol.
Turbo Chain This selects the Turbo Chain protocol.
None This disables ring redundancy.
None
Set as Master
Setting Description Factory Default
Enabled
The TN-5500 is manually selected as the
master.
Disabled
The Turbo Ring or Turbo Ring V2 protocol
will automatically select the master.
Not checked
Redundant Ports
Setting Description Factory Default
1st Port
This specifies which port on the TN-5500
will be used as the first redundant port.
None
2nd Port
This specifies which port on the TN-5500
will be used as the second redundant port.
None
Enable Ring Coupling
Setting Description Factory Default
Enable
This specifies that this TN-5500 will be a
ring coupler.
Disable
This specifies that this TN-5500 is not a ring
coupler.
Not checked
Coupling Port
Setting Description Factory Default
Coupling Port
This specifies which port on the TN-5500
will be used as the coupling port.
None
