10.5 Systems Consisting of Several Racks
Systems with Central Recording of Measuring Values
In systems with several racks, which are not isolated from each other, the following points should
be kept in mind:
- Each rack must have a guaranteed voltage supply. The GND-connectors of all racks must be
interconnected.
- When the central unit respectively the satellites consist of several racks, note that in each rack-
group the GND-connectors must be interconnected.
- The racks must be connected to each other by a CAN bus and the system fail relay must be
connected on each rack.
- The racks are connected by way of the MST modules on the rear with ready-made CAN bus
cables.
- For a “multi-rack” system, contacts 1 and 2 (CAN-A, CAN-B) of the DIL switch on the MIB mod-
ule in the last rack – i.e., the one where the CAN bus ends – should be closed. All DIL switch
contacts 1 and 2 (CAN-A, CAN-B) on the racks in between must be open (Chapter 10.3).
- The setting of the CAN bus bit rate must be the same for all racks and should correspond to
the standard settings defined for the total number of inputs in question (Chapter 10.3).
- Each rack must have it own CAN node number. The standard setting for the first rack is 111
(Chapter 10.3).
- In the case of non-redundant systems, the standard practice is to use the CAN-A bus connec-
tion; when a redundant system is built, the CAN-B is also connected (Chapter 12).
- A cooling fan must be installed and operated for the warmth removal in the installation frame-
work if more than 64 measuring points are fitted with MPI modules.
Connection Notes
The MST Module has been modified to facilitate applying the CAN Bus connections.
Unlike the previous MST module (G status A), the revised version (G status B) has an input and
output for each CAN Bus. For this reason, when connecting several racks via CAN bus, the CAN
Bus T-piece is no longer required. (Art.-No.: 10030080).
In the following, the connection of several racks (BGT) via CAN bus is described for both MST
module variations.
NOTE: For reason of clarity, only one CAN bus is described, the other CAN buses are connected
the same way.
For connections and terminal assignment see Chapter 10.10.
NOTE: The system fault relay must be wired up for all racks!
Signification: St = Plug
B = Socket
(stands for plug connectors at the respective line)
