6.9 ID Rack Assignment in decimal and hexadecimal figures
Fig. 54 ID Rack Assignment in decimal and hexadecimal figures
Rack 1 Slot 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
ID
dec.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
ID
hex.
123456789ABCDEF10
Rack 2 Slot 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
ID
dec.
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
ID
hex.
11 12 13 14 15 16 17 18 19 1A 1B 1C 1D 1E 1F 20
Rack 3 Slot 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
ID
dec.
33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
ID
hex.
21 22 23 24 25 26 27 28 29 2A 2B 2C 2D 2E 2F 30
Rack 4 Slot 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
ID
dec.
49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64
ID
hex.
31 32 33 34 35 36 37 38 39 3A 3B 3C 3D 3E 3F 40
Rack 5 Slot 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
ID
dec.
65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
ID
hex.
41 42 43 44 45 46 47 48 49 4A 4B 4C 4D 4E 4F 50
Rack 6 Slot 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
ID
dec.
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96
ID
hex.
51 52 53 54 55 56 57 58 59 5A 5B 5C 5D 5E 5F 60
Rack 7 Slot 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
ID
dec.
97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112
ID
hex.
61 62 63 64 65 66 67 68 69 6A 6B 6C 6D 6E 6F 70
Rack 8 Slot 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
ID
dec.
113 114 115 116 117 118 119 120 121 122 123 124 125 126 127
ID
hex.
71 72 73 74 75 76 77 78 79 7A 7B 7C 7D 7E 7F
Slot No. 16 of a rack is reserved for the MDO only. Only one MDO can be contacted in one
system.
