15.12 SUPREMA Sensor Data Sheet Contact
Fig. 191
The cable screen is only connected to the SUPREMA.
Connection
data:
Maximum nominal current 8 mA
Maximum nominal voltage 15 V
Power consumption ≤1.0 W (including cable length)
Cable type 2-core, 80 % screened
Maximum loop resistance 50 ohms
Maximum cable length 2000 m (at 1.5 mm
2
cross section per wire
Cross section per wire al-
lowed
0.5 ... 2.5 mm
2
Conditions
for use:
Mounting depending on the switch type
Ingress protection -
Explosion protection no
Certificate depending on the switch type
Temperature depending on the switch type
Humidity depending on the switch type
Pressure depending on the switch type
Weight depending on the switch type
Dimensions W x D x H depending on the switch type
Housing material depending on the switch type
