Open or short-circuit fault indication at the following configuration:
S101: 1 and 2 = ON; 3 and 4 = OFF (External power supply)
S102: 1 and 2 = ON; 3 and 4 = OFF (Contact type NO)
S103: 3 and 4 = ON (overall line control)
X = Signal failure (FAIL) XX = Signal - Alarm N = Failure case has no effect
Open-circuit
at the MAT
(TS) Module
Wire
-X1/1
Wire
-X1/2
Wire
-X1/4
Wire
-X1/5
Disconnect plug of
MAT (TS)
Failure
indication
XXXXX
Open-circuit
at max. cable
length
Wire
-X1/1
Wire
-X1/2
Wire
-X1/4
Wire
-X1/4
Failure
indication
XXXX
Short-circuit at the
MAT (TS) Module
Wire
-X1/1/ with
X1/2
Wire
-X1/1/ with
X1/2
Wire
-X1/1/ with
X1/2
Wire
-X2/4
Wire
-X2/5
Wire
-X4/5
Failure
indication
XXNXXX
Short-circuit at
max. cable length
Wire
-X1/1/ with
X1/2
Wire
-X1/1/ with
X1/4
Wire
-X1/1/ with
X1/5
Wire
-X2/4
Wire
-X2/5
Wire
-X4/5
Failure
indication
XXNXXX
