SUPREMATouch
98
Maintenance and Service
MSA
US
13 program error MCP,
MDO
Application pro-
gram error
Restart X X Application
error code
Additional
data [error
code de-
pended]
Normally software problems
[not plausible internal soft-
ware status]
14 data error MCP,
MDO
Application pro-
gram error
Restart X X Application
error code
Additional
data [error
code de-
pended]
Normally software problems
[not plausible internal soft-
ware data]
Often sequence error of No. 9
or 10
15 system config-
uration error
MCP The system con-
figuration detect-
ed does not
correspond to
the configuration
stored or is not
consistent
Restart X X Configura-
tion error
code
Additional
data [error
code de-
pended]
Modules on wrong plug posi-
tion? Several racks of the
same ID [switch] in the sys-
tem?
MDA Module in invalid
slot
Restart X X Slot number Always 0 The module is in an invalid
slot
MAO,
MGO
Module in invalid
slot
Restart X X Always 0 Always 0 The module is in an invalid
slot
16 data acquisi-
tion error
MDA SPI communica-
tion error be-
tween MDA and
MAI
SPI commu-
nication all
right again
X X SPI error
code
Additional
data [error
code de-
pended]
MAI or MDA defect. Can also
be caused by defect rack. Al-
ways appears if a MDA but not
a MAI, is being plugged in a
rack.
MGO SPI communica-
tion error be-
tween MDA and
MAI or at digital
outputs [MGO]
SPI commu-
nication re-
spectively
outputs all
right again
XX1-5 →
number of er-
roneous out-
put block
FF → hard-
ware defect
MGO:
diagnosis
code
Outputs short circuited or
open or module defect.
No.
Failure Mes-
sage Text
Module
Appears in
case of
Disappears
in case of
Error
LED
Fail
LED
Info 1
[BYTE]
Info 2
[DWORD]
Remarks/ Remedial action
