Installation
SUPREMATouch
191
US
MRO10 8 TS Module
The terminals are assigned as follows:
Fig. 127 MRO 8 TS Module, Terminal Assignment
MRO20 8 TS Module
The terminals are assigned as follows:
Relay No. Terminal No. Contact
11 NO
2C
3NC
213 NO
14 C
15 NC
34 NO
5C
6NC
416 NO
17 C
18 NC
57 NO
8C
9NC
619 NO
20 C
21 NC
710 NO
11 C
12 NC
822 NO
23 C
24 NC
Relay Number Terminal Contact
1
1NC
2M
3NO
25 NC
26 M
27 NO
