SUPREMA Sensor Data Sheets
SUPREMA
261
US
Confuguration data:
All other inputs in the Settings/Measuring Points menu may be chosen freely.
NOTE: The potential-free contacts can also be used to carry out a lamp test or relay status of con-
tacts. Use of these contacts for this purpose is identical to an alarm and will also trigger the col-
lective alarm.
Settings/Measuring points/Sen-
sor data
Sensor Pressure button
Measuring range 0 ... 100
Unity Units any
1
st
alarm/level 30.00
Above alarm level Alarm contact is shut
Below alarm level Alarm contact is opened
Latching Alarm latching
2
nd
to 4
th
alarm/level deactivated
It is recommended to delete the 2nd to 4th alarm. To do so, enter the associated alarm
limit value fields, press "CLEAR" and commit with "OK".
