SUPREMA Sensor Data Sheets
SUPREMA
263
US
Simulation of normal operation / Alarm / RESET / Open or short-circuit fault indication:
Conditions
for use:
Mounting Wall mounting
Ingress protection IP 42 according to DIN 400 50
Explosion protection -
Certificate -
Temperature Type SMOKE detector -20 °C to +60 °C
Type HEAT detector -20 °C to +90 °C
Humidity 0 ... 95 % rel. humidity; noncondensing
Pressure 950 ... 1100 hPa
Weight approx. 120 kg
Dimensions Diameter 100 mm x 50 mm
Simulation Effect
Normal operation
END OF LINE resistor 2K2
connected according to circuit diagram
Normal operation
Alarm
END OF LINE resistor 2K2
connected according to circuit diagram
Connect resistor 1.0 K 1% 0.5 W
between terminals 3 and 4
Alarm message
RESET
Connect wire jumper between terminals 3 and 4
Alarm message disappears, normal operation.
Failure message after 45 s maximum appears.
Open-circuit of line
END OF LINE resistor 2K2 not connected
Failure message
Line short-circuit
END OF LINE resistor short-circuited
Failure message after 45 s maximum.
