SUPREMA Sensor Data Sheets
SUPREMA
265
US
Simulation of normal operation / Alarm / RESET / Open or short-circuit fault indication:
Conditions
for use:
Mounting Wall mounting
Ingress protection IP 42 according to DIN 400 50
Explosion protection -
Certificate -
Temperature Type SMOKE detector -20 °C to +60 °C
Type HEAT detector -20 °C to +90 °C
Humidity 0 ... 95 % rel. humidity; noncondensing
Pressure 950 ... 1100 hPa
Weight approx. 120 kg
Dimensions Diameter 100 mm x 50 mm
Housing material Plastic
Simulation Effect
Normal operation
External power supply 23 ... 32 V
connected according to circuit diagram
END OF LINE resistor 2K2 connected accord-
ing to circuit diagram
Normal operation
Alarm
External power supply 23 ... 32 V
connected according to circuit diagram
END OF LINE resistor 2K2
connected according to circuit diagram
Connect resistor 1.0 K 1 % 0.5 W between ter-
minal 3 and 4
Alarm message
RESET
Connect wire jumper between terminals 3 and 4
Alarm message disappears, normal operation.
After max. 45 s failure message appears.
Open-circuit of line
External power supply 23 ... 32 V
connected according to circuit diagram
END OF LINE resistor 2K2 not connected
Failure message
Line short-circuit
External power supply 23 ... 32 V
connected according to circuit diagram
END OF LINE resistor short-circuited
Failure message after 45 s maximum.
Interruption of the supply voltage
External power supply 23 ... 32 V
not connected
END OF LINE resistor 2K2
connected according to circuit diagram
Failure message
