SUPREMA Sensor Data Sheets
SUPREMA
269
US
Simulation of normal operation / Alarm / RESET / Open or short-circuit fault indication:
Conditions
for use:
Mounting Wall mounting
Ingress protection IP 42 according to DIN 400 50
Explosion protection -
Certificate -
Temperature -
Humidity -
Pressure -
Weight -
Dimensions 125 x 125 x 36 mm
Housing material Plastic
Simulation Effect
Normal operation
END OF LINE resistor 2K2
connected according to circuit diagram
Normal operation
Alarm
END OF LINE resistor 2K2
connected according to circuit diagram
Connect resistor 1.0 K 1% 0.5 W
between terminals 3 and 4
Alarm message
RESET
Connect wire jumper between terminals 3 and 4
Alarm message disappears, normal operation.
After max. 45 s failure message appears.
Open-circuit of line
END OF LINE resistor 2K2 not connected
Failure message
Line short-circuit
END OF LINE resistor short-circuited
Failure message
