SUPREMA Sensor Data Sheets
SUPREMA
291
US
Constant cable length of sen-
sor
2.0 m
Conditions
for use:
Mounting Wall mounting
Explosion protection/Sensor II 2 G EEx d IIC T3 (-40 °C ... +160 °C) –
HT
Certificate/Sensor INERIS 03 ATEX 0208
Dimensions W x D x H
Weight
Temperature
100 x 100 x 100 mm
400 g
-40 °C ... +55 °C (T5)/-40 °C ... +40 °C
(T6)
Terminal box EEx e 2 x M25 x 1.5 mm
Dimensions W x D x H
Weight
Temperature
KEMA 99 ATEX 3853
90 x 90 x 75 mm
490 g
-20 °C ... +55 °C (T5)/-20 °C ... +40 °C
(T6)
Humidity 5 ... 95 % rel. humidity; noncondensing
Pressure 800 ... 1200 hPa
For further details see operation manual. (Order No.: 10052472)
Startup: Presetting required —> before first calibration and when changing sensor
Presetting: Connect digital voltmeter to MAI card jacks.
Bridge current setting —> 310 mA
Zero adjustment by zero gas —> Zero setting to Ua = 400 … 450 mV
Sensitivity adjustment with measuring gas -> Measuring range level
Ua = 1950 ... 2100 mV or by means of the value of the existing gas concentration
according to Ua (mV) = C (Span gas concentration in % of measuring range)
/ 100 * 1600 + 400
Warm-up
period:
15 min minutes for presetting,
2 hours for calibration
Function test: Span gas application via: test cap with 1,0 l/ min. (Order No. 10049316)
Calibration: Calibration procedure according to SUPREMA operation manual
For measuring components allowed, measuring ranges, lower alarm levels and
conditions for calibration see list of components (Order No.: D0792420)
Possible other measuring components and measuring ranges on request.
