CSA certification of the 4-20 mA input does not include or imply approval of the gas detection ap-
paratus such as sensors, transmitters, or devices connected to the system. In order to maintain
CSA Certification of the system, all 4-20 mA gas detection instruments connected to the input
must also be CSA Certified.
Open-circuit at the MAT
(TS) Module
Wire -X1/1 Wire -X1/4 Disconnect plug
of MAT (TS)
Failure indication X X X
Open-circuit at max. ca-
ble length
Wire -X1/1 Wire -X1/4
Failure indication X X
Short-circuit at the MAT
(TS) Module
Wire -X1/1/ -X1/4
Failure indication X
Short-circuit at max.
cable length
Wire -X1/1/ -X1/4
Failure indication X
