96
©
2019 MST Global Commercial in Confidence
A
XON Digital Plat
f
orm
User Manual
Revision A
Switch Configuration
These settings control switch ports 1-8 and assign VLANs. The following settings are available for all
ports. Note that the x in each parameter is replaced by the relevant port number.
Field Description
switch.port.x.enabled
0
: Disabled
1
: Enabled
switch.port.x.name The name of the port
switch.port.x.vlan_mode
1
: ACCESS_PORT
2
: TRUNK_PORT
switch.port.x.vlan_membership Bitmask of the VLAN ID of which the port is a member.
Additionally, ports 5-8 include the following:
Field Description
switch.port.x.speed
1
: 10 HALF
2
: 10 FULL
3
: 100 HALF
4
: 100 FULL
5
: 1000 HALF
6
: 1000 FULL
7
: AUTO
PoE (Power Over Ethernet)
This setting controls the 48VDC PoE supply feature, and is enabled by default.
Field Description
switch.poe.enabled
0
: Disabled
1
: Enabled
