7
©
2019 MST Global Commercial in Confidence
A
XON Di
g
ital
Platform
User
Chapter 3: AXON Air module
Topics:
Hardware overview
Daisy Chaining of AXON Air units
This chapter presents the features and functions of the AXON Air module and shows how it
integrates with the AXON Core unit and the network.
Mine Site Technologies' AXON Air is a key member and an important building block within the MST
AXON family of products, it provides wireless network access for mining environments that do not
require Intrinsically Safe equipment and consists of a Wi-Fi Access Point and 2-port Ethernet switch
for daisy chaining. AXON Air supports meshing (802.11s protocol) and can be used as a mesh
gateway or a wireless bridge between two wired subnets.
AXON Air has the following features:
One Wi-Fi Radio, 802.11 a/b/g/n, 2 x 2 MIMO, 2.4 or 5Ghz
6 x SSIDs
VLAN (IEEE 802.1Q) protocol support
LLDP (802.1AB) protocol support
SNMP (read only) protocol support
QoS (P802.1p) protocol support
WEP/ WPA/ WPA2 security protocols support
Two 1Gbps Ethernet ports with proprietary Power over Ethernet power supply capability
The unit gets its power from the upstream PoE ports and passes it through to the next access
point in the chain via the downstream port. AXON Air negotiates a PoE+ Class 4 power
requirement, whilst drawing 4W nominally.
Rigid hard plastic enclosure, suitable for mining environment sealed to comply with an Ingress
Protection rating of IP65
For detailed specifications on AXON Air, see AXON Air Specifications
