A
XON Digital Plat
f
orm
User Manual
Revision A
107
©
2019 MST Global Commercial in Confidence
Appendix F: Maintenance Check List
It is recommended all AXON Core and AXON Air units, antennas, cables and connectors are inspected at
regular intervals. A maintenance checklist is provided below.
Inspection
A
ction
Power
V
erify the voltage at each AXON Core is above 20VDC (using the web
browser interface).
Structural Inspect the outer case for any structural damage.
Check the case is firmly closed.
Check there is no excessive damage or markings to paintwork.
Composite cables Check all composite cables are connected and secure.
Coaxial cables Check coaxial cable connections are securely fastened and properly
insulated to AXON Air unit.
Check the coaxial cable for any damage.
A
ntennas Check the antennas for any damage.
Check the antennas' connections to the coaxial cable for any damage
to the insulation or connection.
Check the antennas' directional alignment.
Ethernet connections (PoE) Check all Ethernet cable connections are secure.
Check dust covers are present and secure on unused Ethernet ports.
LEDs Check the power LED is lit green.
Check the status LEDs are blinking green and there are no orange
LED lights
Testing RF TX path for AXON Air
Stand 50M away from AXON Air.
Using a MinePhone handset, verify the signal strength is within
specification. (Refer to commissioning data).
Testing RF RX path for AXON
A
i
r
Stand 50M away from AXON Air with two MST RFID tags.
Open AXON Air web browser interface and select the “Trackingweb
page.
V
erify that the two tags have been detected by the network switch and
check the received signal strength is within specification (Refer to
commissioning data).
